35kv GIS Components GIS Panels Cable Connector Shielding Type With Arrester

Large Image : 35kv GIS Components GIS Panels Cable Connector Shielding Type With Arrester

Product Details:

Place of Origin:	China
Brand Name:	MacweyTEK
Certification:	IEC
Model Number:	HY5WZ-51/134

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	$25
Packaging Details:	carton & pallet
Delivery Time:	18 days
Payment Terms:	T/T
Supply Ability:	10000 piece

Contact Now Chat Now

Detailed Product Description

Name:	GIS Components	Rated Voltage:	51KV
Continuous Operating Voltage:	40.8KV	5KA Lightning Impulse Current Residual Voltage:	134KV
Voltage Under DC 1mA:	U1mA≥73KV	Leaking Current At DC 0.75U1mA:	≤50μA
Highlight:	35kv GIS Components , GIS Panels Cable Connector , Cable Connector Shielding Type

35kv Shielding Type Rear Cable Connector with Arrester for GIS Panels Featuring 51KV Rated Voltage and 40.8KV Continuous Operating Voltage

Product Specifications

Type: HY5WZ-51/134 (connector with arrestor)

Connector Technical Parameters

Item	Data
Rated voltage	51KV
Continuous operating voltage	40.8KV
5KA lightning impulse current residual voltage	134KV
Voltage under DC 1mA	U1mA≥73KV
Leaking current at DC 0.75U1mA	≤50μA
2ms rectangular current withstand	400A

Arrester Performance Parameters

Item	JHY5WZ-42/120	JHY5WZ-51/134
System nominal voltage	35k	35
Rated current	42	51
Continuous operation voltage	34	40.8
5KA lightning impulse current residual voltage	120	134
At DC 1mA voltage U1mA	≥65	≥73
Leaking current at DC 0.75mA	≤50	≤50
Large current impulse withstand	65	65
2ms rectangular current withstand	400	400
