ANSI 52-1 Ceramic Suspension Disc Insulator 11kV With Ball And Socket Type End Fitting

Large Image : ANSI 52-1 Ceramic Suspension Disc Insulator 11kV With Ball And Socket Type End Fitting

Product Details:

Place of Origin:	China
Brand Name:	MacweyTEK
Certification:	IEC
Model Number:	FXBW

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	$5
Packaging Details:	cartons
Delivery Time:	10 days
Payment Terms:	T/T
Supply Ability:	20000

Contact Now Chat Now

Detailed Product Description

Name:	ANSI 52-1	Rated Voltage:	11kV
Structure & Material:	Ball And Socket End Fitting, Hydrophobic Silicone Rubber + FRP Core	Mechanical Strength:	70kN/100kN
Application:	Overhead Distribution Lines (Suspension/Tension)	Core Feature:	Pollution Flashover Resistant, Water-Repellent
Highlight:	ANSI 52-1 , Ceramic Suspension Disc Insulator , Suspension Disc Insulator 11kV

ANSI 52-1 Ceramic Suspension Disc Insulator with Ball and Socket Type End Fitting and Hydrophobic Silicone Rubber for Overhead Line Insulation

The 11kV Polymer Disc Insulator is engineered for overhead distribution lines, providing reliable performance for both suspension and tension applications. Featuring a ball and socket type end fitting design, it ensures secure and standardized connections in power line systems.

Key Features

Constructed from high-quality hydrophobic silicone rubber for superior pollution flashover resistance
Excellent electrical insulation performance in harsh environmental conditions
Water-repellent (hydrophobic) properties prevent conductive water film formation
Available in two mechanical strength options: 70kN and 100kN
High-strength fiber-reinforced epoxy core (FRP rod) for tensile resistance and stability
Starting price: USD 2.5 per piece (EXW)

Technical Specifications

Model	Rated Voltage (kV)	Mechanical Load (kN)	Section Length (mm)	Arcing Distance (mm)	Creepage Distance (mm)	Coupling Size	Lightning Impulse Withstand Voltage (kV)	Power Frequency Withstand Voltage (kV), dry	Power Frequency Withstand Voltage (kV), wet
FXBW-11/70	11	70	266	150	305	16	95	55	50
FXBW-11/100	11	100	290	220	450	16	145	80	70
